| Model | Caddx Ant |
| Image Sensor | 1/3" CMOS Sensor |
| Horizontal Resolution | 1200 TVL |
| TV System | NTSC or PAL(Switchable) |
| Menu | Supported |
| Aspect Ratio | 16:9 or 4:3 |
| Sync | Internal |
| Electronic Shutter | PAL: 1/50–100,000; NTSC: 1/60–100,000 |
| SNR | >52 dB (AGC OFF) |
| Video Output | CVBS |
| Lens | 1.8 mm |
| Minimum Illumination | 0.001 Lux @ F1.2 |
| Automatic Gain Control (AGC) | Yes |
| Backlight Compensation (BLC) | Yes |
| WDR | Global WDR |
| DNR | 3D DNR |
| Dimensions | 14 × 14 mm (bracket to 19 × 19 mm) |
| Wide Voltage Input | DC 3.7–18V |
| Operating Temperature | -20°C to +60°C |
| Operating Humidity | 20%–80% |
| Weight | 2 g (N.W.) |
